Abstract

Esophageal neuroendocrine neoplasms (E-NENs) are much rarer than other gastroentero- pancreatic neuroendocrine neoplasms, the majority showing aggressive behavior with early dissemination and poor prognosis. Among E-NENs, exceptionally rare well differentiated neuroendocrine tumors (E-NET) and more frequent esophageal poorly differentiated neuroendocrine carcinomas (E-NEC) and mixed neuroendocrine-non neuroendocrine neoplasms (MiNEN) can be recognized. E-NECs usually exhibit a small cell morphology or mixed small and large cells. Esophageal MiNEN are composed of NEC component admixed with adenocarcinoma or squamous cell carcinoma. Gastric (G) NENs encompass a wide spectrum of entities ranging from indolent G-NETs to highly aggressive G-NECs and MiNENs. Among G-NETs, ECL-cell NETs are the most common and, although composed of histamine-producing cells, are a heterogeneous group of neoplastic proliferations showing different clinical and prognostic features depending on the patient’s clinico-pathological background including the morphology of the peri-tumoral mucosa, gastrin serum levels, presence or absence of antral G-cell hyperplasia, and presence or absence of MEN1 syndrome. In general, NET associated with hypergastrinemia show a better outcome than NET not associated with hypergastrinemia. G-NECs and MiNENs are aggressive neoplasms more frequently observed in males and associated with a dismal prognosis.

NEUROENDOCRINE NEOPLASMS OF THE ESOPHAGUS

Introduction

Esophageal neuroendocrine neoplasms (E-NENs) are much rarer than other gastro-entero-pancreatic neuroendocrine tumors accounting for only 0.04-1%. More than 4000 cases have been described in the international literature ¹, where E-NENs represent 0.03-0.05% of all esophageal malignancies ^2-4. Their incidence has been increased in the last decades, probably as a secondary effect of improvement in diagnosis and clinician awareness. The majority of E-NENs show an aggressive behavior with early dissemination and poor prognosis depending on size and grade. Unfortunately, the rarity of this neoplasm has not yet permitted the prospective recruitment of patients in clinical trials, in order to establish biological features and the optimal therapeutic regimen.

Clinical presentation

Mean age of E-NEN patients at diagnosis is 66 years with a male prevalence (6:1 ratio). More than 50% of cases originate in the lower third of the esophagus ⁵. Only a small fraction of patients with E-NEN are asymptomatic and incidentally discovered during endoscopy, while most patients present with dysphagia and weight loss. Less frequent symptoms are pain, hoarseness, and bleeding¹. Given the frequent high grade of these neoplasms, carcinoid syndrome is extremely rare, while paraneoplastic syndromes are slightly more frequent.

Less than 1% of E-NENs are well differentiated, while the great majority are high grade poorly differentiated small cell neuroendocrine carcinomas, which present with common lymph node and distant metastases (31-90% of cases) ^1,6. Distant metastases are usually located in the liver, lung and bone, while brain metastases are relatively rare⁷.

Prognostic factors are unclear because of the rarity of this neoplasm and the scarcity of collected data in international literature. Age, disease extent, TNM classification and type of treatment (local +/- systemic) are the main prognostic factors affecting survival.

E-NENs treatment is dependent on histological subtype, grade and stage, but the most effective therapeutic algorithm has not been established. Guidelines suggest, in analogy with lung small cell neuroendocrine carcinoma, similar therapeutic protocols including chemotherapy, radiotherapy and surgery ⁷. Recently, a retrospective study analyzing 250 stage I-III E-NEN patients, suggests that patients treated with surgical resection plus chemo and/or radiotherapy show a better 2 year survival than patients without surgical resection of the primary tumour ⁸. Radical surgery alone provides limited benefits. Neuroendocrine carcinoma of the esophagus has a worse prognosis in comparison to esophageal adenocarcinoma and squamous cell carcinoma ⁵.

Histological features

DEFINITION AND TERMINOLOGY

E-NENs are defined as epithelial neoplasms with predominant neuroendocrine differentiation ⁷. In this category the following are included: esophageal well differentiated neuroendocrine tumors (E-NET), esophageal poorly differentiated neuroendocrine carcinomas (E-NEC), and mixed neuroendocrine-non neuroendocrine neoplasms (MiNEN).

E-NETs (grade 1 to 3) are extremely rare; mitotic and Ki67 cut off values for grading are analogous to those applied in other sites. More than 90% of E-NENs are represented by small cell NECs, while a minority by large cell NECs. In a recent case series of 69 consecutive MiNENs, the esophagus and gastro-esophageal junction was identified as the second commonest site of origin (15.9% of cases) after colon-rectum ⁹. Among MiNEN, the most frequently reported type is the Mixed AdenoNeuroendocrine carcinoma (MANEC).

MICROSCOPIC DESCRIPTION

E-NETs are characterized by a proliferation of uniform, medium sized cells with abundant cytoplasm, ovoid nuclei with dispersed ‘salt and pepper’ chromatin and inconspicuous nucleoli, growing in insular, trabecular or cribriform pattern with interposed well-vascularized stroma.

E-NECs are more frequently of the small cell subtype composed of small round, ovoid or spindle-like cells with hyperchromatic nuclei with dense chromatin organized in ample solid insulae or festoons, with multifocal necrosis and frequent mitoses (Fig. 1). A relatively small proportion of E-NECs are composed of large cells with basophilic cytoplasm and marked nuclear atypia with prominent nucleoli.

MiNEN are usually composed of NEC admixed with an adenocarcinoma or squamous cell carcinoma (with the two components histologically and immunohistochemically distinguishable). Less than 10 cases of MiNEN composed of NEC and squamous cell carcinoma of the esophagus are reported in the international literature as case reports ^10-11.

Immunohistochemical and molecular markers

Synaptophysin, chromogranin A, and CD56 immunohistochemical stains are used to demonstrate neuroendocrine differentiation and positivity for these markers varies between 60% and 100% of cases with chromogranin A expression usually focal and/or faint in E-NECs.

Hormones can be expressed by neoplastic cells including serotonin, glucagon and gastrin, but in general in NET.

Alcian blu-PAS and cytocheratin 7 can be used to demonstrate and quantify the adenocarcinomatous component in MiNEN, while p63, p40 and cytokeratin 5/6 are used to confirm the squamous component.

No significant data on molecular biology of these tumors is available.

Differential diagnosis

The main differential diagnosis for E-NENs, in particular E-NECs, is with metastases from lung small cell NEC. Clinical history and imaging are of particular effort in this setting, since transcription factor immunohistochemistry is not useful.

Importantly, MiNENs have to been distinguished from carcinoma with focal neuroendocrine differentiation applying two main diagnostic criteria: the recognition of structural features of neuroendocrine morphology (i.e. organoid or solid growth pattern) and the extension of each component (at least 30%).

NEUROENDOCRINE NEOPLASMS OF THE STOMACH

Introduction

NENs of the stomach include small indolent NETs and highly aggressive NECs. They account for about 4% of all NENs with an estimated annual incidence of 0.4 cases/100,000 persons in both USA and Europe ^12-13. Rare MiNENs are also observed.

GASTRIC NEUROENDOCRINE TUMORS (NETs)

ECL-cell NETs

Most gastric NETs are composed of ECL-cells and are located in the corpus-fundus (oxyntic) mucosa (Tab. I). They are commonly separated into three different clinical-pathological subtypes with prognosticsignificance, gastrin-dependent type 1 and type 2 of proven ECL-cell nature and gastrin independent type 3 of less obvious cell type characterization ^14-17.

All gastric NETs are graded into three proliferative grades, according to WHO 2019 correlating with prognosis ^16-17. The best prognostic stratification of patients is obtained by coupling the above clinico-pathological classification and the WHO tumor proliferative grade ¹⁸.

All gastric NETs are characterized by the expression of chromogranin A, synaptophysin and somatostatin receptor type 2A. ECL-cell NETs are also positive for VMAT2 and histidine decarboxylase (HDC). A few scattered cells may be immunoreactive for serotonin, ghrelin, somatostatin, and alpha-hCG.

Type 1

Type 1 ECL-cell NETs are the most common type, arise in a background of autoimmune chronic atrophic gastritis associated with reduction/lack of acid secretion and consequent antral G-cells hyperplasia and hypergastrinemia. Patients are often female and may have autoantibodies against intrinsic factor and/or parietal cells. Due to the impaired absorption of vitamin B12, a sub-group of patients may also present macrocytic anemia.

Tumors are generally multiple, small (< 1 cm), limited to the mucosa or submucosa and located in the corpus-fundus. Only larger tumors (> 1 cm) may infiltrate the muscularis propria or beyond. They are composed of well-differentiated cells with monomorphic nuclei, inconspicuous nucleoli, and fairly abundant eosinophilic cytoplasm, arranged in small microlobular and/or trabecular structures (Fig. 2A). Mitotic activity is absent or low and necrosis is lacking. Most cases are G1, but G2 and exceptional G3 cases have been described ¹⁷. The surrounding oxyntic mucosa is atrophic, showing ECL-cell hyperplasia and dysplasia (Fig. 2A-B). In the antral mucosa G-cells hyperplasia is the rule.

Patients with type 1 ECL-cell NETs have an excellent prognosis with a 10-year survival rate of more than 90%. No significant difference for patient outcome was found between G1 and G2 cases, suggesting tumor grade may not be the most important predictor in this subgroup ¹⁷. The risk for lymph node metastasis correlates with tumor size and deep wall invasion ¹⁷.

Type 2

Type 2 ECL-cell NETs account for about 5-7% of ECL-cell NETs and are observed in patients with MEN1 syndrome, without gender predilection. Tumors are generally multiple, measure < 2 cm and arise in hypertrophic-hypersecretory oxyntic mucosa due to gastrin stimulation. Hyperplastic and dysplastic ECL-cell proliferations are observed in the hypertrophic peritumoral mucosa. Hypergastrinemia is caused by a duodenal or, more rarely, a pancreatic gastrinoma. Patients with sporadic gastrinomas do not develop ECL-cell NETs ¹⁹, suggesting the MEN1 defect is required for ECL-cell transformation upon gastrin stimulus ²⁰.

Type 3

Type 3 NETs were traditionally considered ECL-cell NETs. However, since histamine production or typical “ECL-type” secretory granules were not demonstrated in all cases, the designation ECL-cell has been removed in the last WHO classification ²¹. Type 3 NETs account for about 10-15% of gastric NETs and are more frequent in males than in females. Patients do not associate with hypergastrinemia and/or chronic autoimmune atrophic gastritis and may present symptoms related to tumor growth or metastatic dissemination.

Type 3 NETs are solitary and large lesions composed of well differentiated neuroendocrine cells frequently invading the muscularis propria and the sub-serosa (Fig. 2C). Lymph node and distant metastases are not rare. Most cases are G1 or G2, but G3 NETs were described ¹⁶. The diagnosis on small biopsy may be a challenge and is achieved by evaluating the peritumoral mucosa which is usually normal or with minimal gastritis (Fig. 2C-D).

The prognosis of type 3 NETs depends on grade and stage with a 10-year disease-specific survival of about 50% ^16-17.

Provisional types

Two additional types have recently been proposed, which are worth being considered while awaiting full clinico-pathologic and/or biochemical characterization.

Provisional Type 4 ECL-cell NETs were described in association with achlorhydria, parietal cell hyperplasia and hypergastrinemia. The gastric mucosa shows dilated oxyntic glands with inspissated secretory luminal material and parietal cells with often vacuolated abundant eosinophilic cytoplasm ^22-23. The pathogenesis was linked to inappropriate acid secretion from functional defective parietal cells with mutated gastric proton pump α-subunit, antral-G cell hyperplasia and hypergastrinemia. Only two cases were carefully documented, one of which with lymph node metastases ²³.

Provisional Type 5 ECL-cell NETs arising in moderate hypergastrinemic patients treated continuously for a long time (at least one year) with PPI, without autoimmune chronic atrophic gastritis, gastrinoma, and MEN1 syndrome have recently been described ²⁴. Since these tumors are associated with a normal or slightly hyperplastic peri-tumoral oxyntic mucosa, they may mimic in part type 3 NETs, from which they need to be differentiated due to the different prognosis ²⁵. Indeed, this ECL-cell NET subtype shows a better behavior that type 3 NET not requiring an aggressive surgical approach. Tumors are slightly more frequent in males. Lymph node metastases have been described in about 15% of patients, but prognosis is excellent.

Commentary on provisional types: a report on a familial cluster of classical Type 1 ECL-cell tumors demonstrated a high incidence of mutation of the ATP4A proton pump gene ²⁶. Although this heritable condition defined a specific clinical profile (younger age of onset, higher malignancy and iron deficiency anemia), it represents a proof of concept that gastrin dependent ECL-cell NETs may result from the combination of both epigenetic and predisposing genetic factors, either known (MEN1 syndrome genetic changes) or presently unknown. This possibility requires careful investigation, especially concerning provisional types.

Other gastric NETs

G-cell, D-cell, and EC-cell NETs are rare (about 5% of all gastric NENs) and usually non-functioning. Gastrin-producing G-cell NETs are generally small, located in proximity of the pylorus and are composed of well-differentiated neuroendocrine cells forming thin trabeculae or gyriform structures. Neoplastic cells are positive for neuroendocrine markers, somatostatin receptor (subtype 2A), and gastrin. Somatostatin-producing D-cell NETs are extremely rare and located in the antrum. They are composed of well-differentiated monomorphic cells positive for chromogranin A, synaptophysin and somatostatin. In general, both G-cell and D-cell NETs are indolent with excellent prognosis, even in the presence of deep wall invasion or lymph node metastasis ¹³. EC-cell NETs may arise in any part of the stomach and are composed of well-differentiated cells with intense eosinophilic cytoplasm in nests with a peripheral palisading. Tumor cells are positive for general neuroendocrine markers, serotonin, CDX2, and somatostatin receptor subtype 2A.

GASTRIC NEUROENDOCRINE CARCINOMA (NEC)

Gastric NECs account for about 6-21% of gastric NENs and usually arise in the antral or cardial regions. Males are more frequently affected (male/female ratio of 2:1) with 65 years (range 41-76 years). Patients generally present non-specific symptoms due to local growth or metastatic dissemination. Usually large lesions, gastric NECs are small and large cell types at histology. Neoplastic cells are positive for synaptophysin while chromogranin A is either faint or expressed with a peripheral or para-nuclear dot-like pattern. NECs may also express nuclear TTF1 or CDX2. Patients’ prognosis is dismal prognosis with survival usually measured in months.

GASTRIC MIXED NEUROENDOCRINE-NON NEUROENDOCRINE NEOPLASM (MiNEN)

MiNEN are usually large, polypoid, ulcerating or stenotic lesions. The neuroendocrine component is often a NEC (small or large cell subtypes) and only rarely a NET. The non-neuroendocrine component is generally an adenocarcinoma or, rarely, a squamous cell carcinoma especially when in the cardial region. MiNENs composed by adenocarcinoma and NEC (MANEC) account for about 20% of all digestive MiNENs ²⁷. Patients have a poor prognosis and the Ki67 proliferative index of the NEC component correlates with prognosis ²⁷.

Rare cases of adenoma associated with NET have also been reported ²⁸.

Figures and tables

Figure 1.(A) Esophageal small cell neuroendocrine carcinoma undermining normal squamous esophageal mucosa; H&E, magnification 4x. (B) Small cell neuroendocrine carcinoma infiltrating the muscular wall of the esophagus; H&E, magnification 10x. (C) Diffuse positivity of neoplastic cells for synaptophysin, magnification 20x. (D) Faint, dot-like, positivity for Chromogranin A; magnification 20x. (E) High proliferative index, 80% (Ki-67 stain), magnification 20x.

Figure 2.Type 1 ECL-cell NET is composed of well-differentiated cells arranged in small microlobular and/or trabecular structures (A, bottom). The peritumoral oxyntic mucosa (A, top) is atrophic with diffuse intestinal metaplasia and shows ECL-cell linear and micronodular hyperplasia, easily detected with chromogranin A immunostaining (B). Type 3 NETs is composed of well differentiated neuroendocrine cells as well, deeply invading the gastric wall (C, right). Peritumoral oxyntic mucosa is normal (C, left) without ECL-cell proliferations (D).

References

1. Giannetta E, Guarnotta V, Rota F. A rare rarity: neuroendocrine tumor of the esophagus. Crit Rev Oncol Hematol. 2019; 137:92-107. DOI
2. Babu Kanakasetty G, Dasappa L, Lakshmaiah KC. Clinicopathological profile of pure neuroendocrine neoplasms of the esophagus: a south indian center experience. J Oncol. 2016; 2016:2402417. DOI
3. Yun JP, Zhang MF, Hou JH. Primary small cell carcinoma of the esophagus: clinicopathological and immunohistochemical features of 21 cases. BMC Cancer. 2007; 7:38. DOI
4. Huang Q, Wu H, Nie L. Primary high-grade neuroendocrine carcinoma of the esophagus: a clinicopathologic and immunohistochemical study of 42 resection cases. Am J Surg Pathol. 2013; 37:467-83. DOI
5. Cai W, Ge W, Yuan Y. A 10-year Population-based study of the differences between NECs and carcinomas of the esophagus in terms of clinicopathology and survival. J Cancer. 2019; 10:1520-1527. DOI
6. Egashira A, Morita M, Kumagai R. Neuroendocrine carcinoma of the esophagus: clinicopathological and immunohistochemical features of 14 cases. PLoS One. 2017; 12:e0173501. DOI
7. Ilett EE, Langer SW, Olsen IH. Neuroendocrine Carcinomas of the gastroenteropancreatic system: a comprehensive review. Diagnostics. 2015; 5:119-76. DOI
8. Erdem S, Troxler E, Warschkow R. Is there a role for surgery in patients with Neuroendocrine Tumors of the esophagus? A contemporary view from the NCDB. Ann Surg Oncol. 2020; 27:671-80. DOI
9. Frizziero M, Wang X, Chakrabarty B. Retrospective study on mixed neuroendocrine non-neuroendocrine neoplasms from five European centres. World J Gastroenterol. 2019; 25:5991-6005. DOI
10. Dasari CS, Ozlem U, Kohli DR. Composite neuroendocrine and squamous cell tumor of the esophagus. ACG Case Rep J. 2019; 6:e00248. DOI
11. Yang L, Sun X, Zou Y, Meng X. Small cell type neuroendocrine carcinoma colliding with squamous cell carcinoma at esophagus. Int J Clin Exp Pathol. 2014; 7:1792-5.
12. Dasari A, Shen C, Halperin D. Trends in the incidence, prevalence, and survival outcomes in patients with neuroendocrine tumors in the United States. JAMA Oncol. 2017; 3:1335-42. DOI
13. La Rosa S, Vanoli A. Gastric neuroendocrine neoplasms and related precursors lesions. J Clin Pathol. 2014; 67:938-48. DOI
14. Rindi G, Luinetti O, Cornaggia M. Three subtypes of gastric argyrophil carcinoid and the gastric neuroendocrine carcinoma: a clinicopathologic study. Gastroenterology. 1993; 104:994-1006. DOI
15. Rindi G, Azzoni C, La Rosa S. ECL cell tumor and poorly differentiated endocrine carcinoma of the stomach: prognostic evaluation by pathological analysis. Gastroenterology. 1999; 116:532-42. DOI
16. La Rosa S, Inzani F, Vanoli A. Histologic characterization and improved prognostic evaluation of 209 gastric neuroendocrine neoplasms. Hum Pathol. 2011; 42:1373-84. DOI
17. Vanoli A, La Rosa S, Miceli E. Prognostic evaluations tailored to specific gastric neuroendocrine neoplasms: analysis of 200 cases with extended follow-up. Neuroendocrinology. 2018; 107:114-26. DOI
18. Klöppel G, La Rosa S. Ki67 labeling index: assessment and prognostic role in gastroenteropancreatic neuroendocrine neoplasms. Virchows Arch. 2018; 472:341-9. DOI
19. Peghini PL, Annibale B, Azzoni C. Effect of chronic hypergastrinemia on human enterochromaffin-like cells: insights from patients with sporadic gastrinomas. Gastroenterology. 2002; 123:68-85. DOI
20. Berna MJ, Annibale B, Marignani M. A prospective study of gastric carcinoids and enterochromaffin-like cell changes in multiple endocrine neoplasia type 1 and Zollinger-Ellison syndrome: identification of risk factors. J Clin Endocrinol Metab. 2008; 93:1582-91. DOI
21. La Rosa S, Rindi G, Solcia E, Tang LH. Digestive system tumours. IARC press: Lyon; 2019.
22. Ooi A, Ota M, Katsuda S. An unusual case of multiple gastric carcinoids associated with diffuse endocrine cell hyperplasia and parietal cell hypertrophy. Endocr Pathol. 1995; 6:229-237. DOI
23. Abraham SC, Carney JA, Ooi A. Achlorhydria, parietal cell hyperplasia, and multiple gastric carcinoids: a new disorder. Am J Surg Pathol. 2005; 29:969-75. DOI
24. Trinh VQ, Shi C, Ma C. Gastric neuroendocrine tumors from long-term proton pump inhibitor users are indolent tumors with good prognosis. Histopathology. 2020; 77:865-76. DOI
25. La Rosa S, Solcia E. New insights into the classification of gastric neuroendocrine tumours expanding the spectrum of ECL-cell tumours related to hypergastrinemia. Histopathology. 2020; 77:862-64. DOI
26. Calvete O, Reyes J, Zuñiga S. Exome sequencing identifies ATP4A gene as responsible of an atypical familial type I gastric neuroendocrine tumour. Human Molecular Genetics. 2015; 24:2914-22. DOI
27. Milione M, Maisonneuve P, Pellegrinelli A. Ki67 proliferative index of the neuroendocrine component drives MANEC prognosis. Endocr Relat Cancer. 2018; 25:583-593. DOI
28. La Rosa S, Uccella S, Molinari F. Mixed adenoma well-differentiated neuroendocrine tumor (MANET) of the digestive system: an indolent subtype of mixed neuroendocrine-nonneuroendocrine neoplasm (MiNEN). Am J Surg Pathol. 2018; 42:1503-12. DOI
