A challenging case of pigmented Bowen’s disease and differential diagnosis of pagetoid pigmented skin lesions

UOC Anatomia Patologica, ASST Grande Ospedale Metropolitano Niguarda, Milano
UOC Anatomia Patologica, ASST Fatebenefratelli-Sacco, Milano
UOC Anatomia Patologica, ASO OIRM Sant’Anna, Torino
UOC Anatomia Patologica, ASST Grande Ospedale Metropolitano Niguarda, Milano
Pigmented Pagetoid Bowen’s disease In situ squamous cell carcinoma

Abstract

Differentiation of pagetoid cutaneous neoplasms can be very challenging on hematoxylin and eosin-stained sections. We report a singular case of pigmented pagetoid Bowen’s disease showing transitional features between extramammary Paget’s disease and in situ squamous cell carcinoma.

Introduction

Pigmented Bowen’s disease (BD) is an uncommon type of intraepidermal squamous cell carcinoma, representing less than 2% of all cases of cutaneous Bowen’s disease (BD) 1.

The most common clinical presentation is as pigmented papules or plaques located on sun-exposed areas like face, neck, trunk and extremities, even if cases involving the umbilicus and the perianal area have been reported 2.

Among cutaneous squamous cell carcinomas in situ, only 5% show a nested growth pattern, referred to as pagetoid BD 3 4.

We report a case of pigmented pagetoid BD (PPBD) of the back, clinically mimicking in situ malignant melanoma, and histopathologically characterized by an unusual immunohistochemical profile.

Case report

A 74-year-old woman presented with a slowly and gradually enlarging solitary heavily pigmented lesion of the back, present since more or less for one year. The patient reported a history of repeated sunburns and sun exposure.

The physical examination revealed a solitary dark brown, ill-defined flat lesion, measuring 1.5 x 1 cm in size, clinically suspicious for melanoma (Fig. 1). A wide surgical excision was performed and there has not been evidence of recurrence after 10 months of follow-up.

Materials and methods

The biopsy was formalin fixed and paraffin embedded. Hematoxilin-eosin stained slices were observed at light microscopy, then immunohistochemical reactions for Cam5.2, CK pool, CK7, CK5/6, CK20, CK19, CK 34β 12, EMA, CEA, BerEP4, S100, Melan A, CD117, p63, p16 (Ventana Medical System, Tucson, Arizona) were performed according to the peroxidase-antiperoxidase technique. Histochemical stains for Alcian Blue, PAS and PAS-D were done.

DNA Extraction

The commercial QIAamp DNA Mini Kit (Quiagen, Hilden, Germany) was used according to manufacturers’protocol.

PCR amplification

Real-time PCR is based on the detection of the fluorescence produced by a reporter molecule which increases, as the reaction proceeds. This occurs due to the accumulation of the PCR product with each cycle of amplification.

The commercial Biogen HPV-HR kit (Biodiversity, Brescia, Italy) was used according to manufacturers’protocol. This is an automated qualitative real-time PCR test for detection of DNA from 12 high-risk HPV types (16, 18, 31, 33, 35, 45, 52, 53, 56, 58, 66, 73).

Pathologic findings

Light microscopy revealed a thickening of the involved epidermis, with foci of parakerathosis. The lesion was characterized by an increased amount of melanin-rich epidermal cells in the basal layer and by a significantly increased number of dendritic melanocytes scattered throughout the full epithelial thickness and in intimate association with atypical epithelioid cells. The atypical cellular component was characterized by a moderate amount of pale cytoplasm containing dusty melanin pigment and by malignant appearing nuclei, with coarse chromatin and prominent nucleoli, showing a pagetoid nested intraepithelial growth pattern, with typical and atypical mitotic figures (Fig. 2).

The dermis did not show neoplastic invasion and was characterized by focal dense lymphocytic infiltrate admixed with melanophages. No glandular structures or adenoid growth pattern was evident. The presence of intracytoplasmic mucin was excluded by negative staining for Alcian Blue. PAS and PAS-diastase gave negative staining. The atypical cells resulted strongly positive with cytokeratin AE1/AE3, CK 34β 12, CK 19, EMA, CK5/6 and p63, weakly and focally positive for CK7, while cam 5.2, CK20, CEA, BerEP4, S100, Melan A were negative (Fig. 3). There was strong nuclear and cytoplasmic p16 immunoreactivity in both neoplastic cellular population of the tumor and in melanocytes present in the lesion and at the periphery, in the adiacent skin (Fig. 4). CD117 immunoreactivity resulted intensely positive in melanocytes both intralesional and of peripheral epidermis, while resulted slightly less intensely positive in intralesional keratinocytes and in neoplastic cells, but negative in adjacent non neoplastic keratinocites (Fig. 4).

Real-time PCR genotyping for HPV gave negative result.

The periphery of the tumor showed features of pigmented reticular solar keratosis, characterized by narrow, pigmented trabeculae, with progressive merging between the two lesions.

Discussion

We have described a case of PPBD. Pigmented BD is an uncommon form of in situ squamous cell carcinoma (IS-SCC), that, according to Ragi et al., represents less than 2% of all BD 1. Moreover, a pagetoid growth pattern has been reported to occur in only 5% of cutaneous in situ squamous cell carcinomas 3 4. Pigmented BD is characterized by increased deposition of melanin pigment in the epidermis or papillary dermis, in addition to the typical histopathological features of BD, while pagetoid BD shows an intraepithelial nested growth pattern simulating Paget’s disease.

Assessment of pigmented lesions is an everyday challenge both for dermatologists and dermatopathologists.

The clinical and histopathological differential diagnosis of pigmented BD includes clonal seborrheic keratosis, in situ melanoma, pigmented malignant hidroacanthoma simplex, and pigmented extramammary Paget’s disease (Tabs. I, II) 5-11.

Seborrheic keratosis is a very common lesion developing in middle aged and elder patient, that appears as a warthy plaque, occasionally intensely pigmented, so that can clinically mimick melanoma 12.

This lesion has been demonstrated to be monoclonal, representing more a benign tumor rather than an hyperplasia 13.

In clonal seborrheic keratosis (CSK), tumor cells appear as circumscribed nodules of basaloid cells with an intrepidermal nested growth pattern, the Borst-Jadassohn appearance, but without evidence of cytologic malignancy as in our case 14 15.

In situ melanoma (IS-M) arising within sebhorreic keratosis has been described as a relatively rare entity, although separately they have been well characterized both clinically and histopathologically 16.

If clinical diagnosis is challenging, histology is confirmatory, revealing usual features of seborrheic keratosis and a concomitant proliferation of atypical melanocytes, immunoreactive to S100, HMB45 and melan-A, with a nested and pagetoid intraepidermal growth pattern. On the contrary, our case could be easily distinguished immunophenotypically from malignant melanoma by the expression of epithelial markers and lack of melanoma markers.

Pigmented variant of malignant hidroacanthoma simplex (PMHS) is a very rare entity. Only few cases are reported in the literature, all arising within benign pigmented hidroacanthoma simplex 17 18.

This tumor appears as a nodule or a verrucous hyperkeratotic plaque or an ulcerated lesion with predilection for the lower extremities and the trunk of elderly patients, more frequently males, clinically mimicking seborrheic keratosis or Bowen’s disease. Malignant hidroacanthoma simplex is characterized by the intraepidermal proliferation of basaloid cells with clear cytoplasm and various degrees of nuclear atypia, sharply demarcated from surrounding keratinocytes. These cells contain moderate amounts of glycogen, resulting invariably PAS positive and PAS negative after diastase digestion, althought the diagnostic feature of porocarcinoma are the eccrine ductal formation and intracytoplasmic lumina, better highlighted by CEA and EMA immunostaining. The pigmented variant is characterized by all these features and by the colonization of dendritic pigmented melanocytes as in our case, while both PAS and immunoreactions to CEA gave negative results in the case we reported 17 19.

However, the main and most challenging differential diagnosis is towards pigmented extramammary Paget’s disease (PEPD) 20, a rare entity described clinically by Culberson and Horn 21 and histopathologically by Ho et al. 22.

Both share the presence of pale pagetoid cells containing fine melanin granules within their cytoplasm and of numerous interdigitating dendritic melanocytes. Only 4 well-documented cases were reported in literature, all occurring in the genital or axillary region, while in our case the lesion was located on the back 23 24.

Immunohistochemistry, however, is still the most reliable method to outline a sharp demarcation between Paget’s cells, which are usually strongly positive for CK7, and variably positive for Cam 5.2, CK19, EMA, CEA, Her-2/neu and squamous cells which are negative 25.

There seems to be a significant immunophenotypic overlap between the case we described and extramammary Paget’s disease, that share CK7, CK19 and EMA expression, while CEA and Alcian Blue stain for mucin gave negative results.

P63 positivity favors the diagnostic hypothesis of squamous cell differentiation. It belongs to the p53 gene family, in the skin it is expressed in the epidermis and sebaceous glands, not in eccrine and apocrine glands. It plays an essential role in regulating the proliferation and the differentiation of squamous cells and it seems a useful marker in differential diagnosis between pagetoid BD and extramammary Paget’s disease 26.

In conclusion, on the basis of both morphological and immunophenotypical features, the diagnosis was PPBD/IS-SCC.

In our opinion, Pagetoid IS-SCC, already considered a separate entity in other anatomic districts as esophagus or vulva, should be considered a distinct entity also in the skin27, different from BD or conventional IS-SCC, better characterized by neoplastic cells involving the whole thickness of the epidermis. In fact, it shares more immunophenotypical similarities and overlapping features with pagetoid actinic keratosis 28.

Moreover, we think that if a focal pagetoid spread can be considered a feature in the context of conventional BD, a pure pagetoid pattern, characterizing the whole lesion, is much rarer, and could represent a neoplasm derived by a different cellular clone, since it has been argued that pagetoid IS-SCC arises from a bidirectional stem cell capable of both squamous and glandular differentiation 29.

Strong and diffuse expression of CK19 may probably be correlated with the retention of stem cell characteristics 30.

P16 overexpression may be used as indirect indicator of integrated oncogenic HPV, so we tried to detect the presence of HPV DNA, which was not found. However, p16 overexpression may be due to non-HPV-induced mutation, and according to Conscience et al., it is significantly associated with the location in sun-exposed areas, suggesting a possible induction by UV radiation, and resulting in an increased proliferation 31, which in our case involved both keratinocytes and melanocytes.

Pigmentation of pagetoid neoplastic cells still remains matter of debate. We argue that c-KIT/CD117 positivity of neoplastic cells, intralesional keratinocytes and melanocytes could support the hypothesis that chemotactic factors such as stem cell factor (SCF) and its receptor c-KIT/CD117 may play a role in colonization of the lesion by dendritic melanocytes and in aiding transfer of pigment from intralesional dendritic melanocytes to neoplastic cells 32. In vitro studies reported the evidence that SCF stimulates the proliferation of human melanocytes 33 and in xenografts of normal human skin 34. It seems that SCF/c-KIT signaling could be involved in the pathway of melanocytic activation during UVB-induced pigmentation, probably accompanied by an increased expression of SCF both in keratinocytes and melanocytes 32.

Other studies demonstrated that c-KIT may play a role in the pathogenesis of some dispigmentary disorders like melama and vitiligo 35, as well as that KIT signaling is involved in hyperpigmentation of solar lentigo, resulting in increased melanogenesis of existing melanocytes and in increased large melanosome complexes in keratinocytes 36.

In conclusion, differentiation of pagetoid cutaneous neoplasms can be very challenging on hematoxylin and eosin stained sections. We presented a singular case of pigmented pagetoid IS-SCC/PPBD, as far as we are aware, the first described in detail, expressing focally CK7 and strongly CK19, showing transitional features between extramammary Paget’s disease and IS-SCC.

CK7 is a highly sensitive marker, although not specific, for Paget’s cells, that may be focally or partially expressed in a subset of cutaneous SCCs, especially poorly differentiated tumors 37.

In particularly challenging pagetoid pigmented cutaneous lesions, when more tools are necessary to distinguish SCC from other mimickers, diagnostic accuracy requires an expanded immunohistochemical panel comprising melanocytic markers together with at least CK7, CK19, p63 and CEA.

Figures and tables

Fig. 1.A slowly and gradually enlarging solitary heavily pigmented lesion of the back.

Fig. 2.(A) The lesion was characterized by thickening of the epidermis, with foci of paracherathosis and by an increased amount of melanin-rich epidermal cells in the basal layer (HE, 10x); (B) the lesion had a pagetoid nested intraepithelial growth pattern (HE, 20x); (C) atypical cells characterized by a moderate amount of pale cytoplasm containing dusty melanin pigment and by malignant appearing nuclei, with coarse chromatin and prominent nucleoli (HE, 40x).

Fig. 3.Neoplastic cells were focally positive with CK7 (Fig. 3a; P-AP technique, 40x), strongly and diffusely positive with CK19 (Fig. 3b; P-AP technique, 40x), EMA (Fig. 3c; P-AP technique, 40x) and p63 (Fig. 3d; P-AP technique, 40x).

Fig. 4.(A) strong nuclear and cytoplasmic p16 immunoreactivity in neoplastic cells (P-AP technique, 40x); (B) Melan-A revealed a significantly increased number of dendritic melanocytes scattered throughout the full epithelial thickness and in intimate association with atypical epithelioid cells (P-AP technique, 20x); (C) CD117 immunoreactivity in both neoplastic cellular population of the tumor and in melanocytes present at the periphery (c; P-AP technique, 10x).

Type of lesion Site Sex Age
CSK Round/oval hake Flat/scaly surface May itch Face, chest Shoulders, back No sex predilection Middle aged people
MIS flat Irregular borders Head, neck,upper and lower extremities Females Young adults-until 49 y
Males Over 49 y
PMHS Nodular/verrucous/ Hyperkeratotic plaque Ulcerated Lower extremities Trunk Slight male predilection Sixth-Eighth decade
PEPD Flat/scaly plaques Genital/axillary region Female predilection Sixth-Eighth decade
PPBD Scaly patches or plaques Sun exposed and covered areas No sex predilection Sixth-Eighth decade
Tab. I.Clinical features in differential diagnosis of cutaneous pigmented pagetoid lesions.
Cam5.2 CKAE1-AE3 CK5/6 CK7 CK19 CK20 CK34β E12 EMA BER EP4 CEA Melan A S100 CD117 p63 p16 HER2 NEU
CSK + + + - - - + basal + - - - - - + basal + nests -
MIS - - . - - - - - - - + + + - +/- -
PMHS + + + + lumina + lumina - - + + + lumina - - + + +/- -
PEPD + + -/+ + + - - + + + - - - + - +
PPBD - + + +/- + - + + - - - - +/- + + -
Tab. II.Immunohistochemical profile in differential diagnosis of cutaneous pigmented pagetoid lesions.

References

  1. Ragi G, Turner MS, Klein LE. Pigmented Bowen’s disease and revew of 420 Bowen’s disease lesions. J Dermatol Surg Oncol. 1988; 14:765-9. DOI
  2. Lee JW, Hur J, Yeo KY. A case of pigmented Bowen’s disease. Ann Dermatol. 2009; 21:197-9. DOI
  3. Strayer DS, Santa Cruz DJ. Carcinoma in situ of the skin: a review of histopathology. J Cutan Pathol. 1980; 7:244-59. DOI
  4. Raju RR, Goldblum JR, Hart WR. Pagetoid squamous cell carcinoma in situ (pagetoid Bowen’s disease) of the external genitalia. Int J Gynecol Pathol. 2003; 22:127-35.
  5. Wei EX, Qureshi AA, Han J. Trends in the diagnosis and clinical features of melanoma in situ (MIS) in US men and women: a prospective, observational study. J Am Acad Dermatol. 2016; 75:698-705. DOI
  6. Düşmez Apa D, Aydin O, Polat A. 34-BetaE12 expression in benign and premalignant squamous lesions of skin: relation to cell proliferation (Ki-67). J Exp Clin Cancer Res. 2003; 22:441-5.
  7. Kalegowda IY, Böer-Auer A.. Clonal seborrheic keratosis versus pagetoid Bowen disease: histopathology and role of adjunctive markers. Am J Dermatopathol. 2017; 39:433-9. DOI
  8. Lau J, Kohler S.. Keratin profile of intraepidermal cells in Paget’s disease, extramammary Paget’s disease, and pagetoid squamous cell carcinoma in situ. J Cutan Pathol. 2003; 30:449-54. DOI
  9. Lee JY, Lin MH. Pigmented malignant hidroacanthoma simplex mimicking irritated seborrheic keratosis. J Cutan Pathol. 2006; 33:705-8. DOI
  10. Liegl B, Leibl S, Gogg-Kamerer M. Mammary and extramammary Paget’s disease: an immunohistochemical study of 83 cases. Histopathology. 2007; 50:439-47. DOI
  11. Kiavash K, Kim S, Thompson AD. “Pigmented extramammary Paget disease”. A potential mimicker of malignant melanoma and a pitfall in diagnosis: a case report and review of the literature. Am J Dermatopathol. 2019; 41:45-9. DOI
  12. Matz H, Orion E, Ruocco V. Clinical simulators of melanoma. Clin Dermatol. 2002; 20:212-21. DOI
  13. Nakamura H, Hirota S, Adachi S. Clonal nature of seborrheic keratosis demonstrated by using the polymorphism of the human androgen receptor locus as a marker. J Invest Dermatol. 2001; 116:506-10. DOI
  14. Zalaudek I, Ferrara G, Argenziano G.. Clonal seborrheic keratosis: a dermoscopic pitfall. Arch Dermatol. 2004; 140:1169-70. DOI
  15. Neuhaus IM, LeBoit PE, McCalmont TM. Seborrheic keratosis with basal clear cells: a distinctive microscopic mimic of melanoma in situ. J Am Acad Dermatol. 2006; 54:132-5. DOI
  16. Repertinger S, Wang J, Adickes E. Melanoma in-situ arising in seborrheic keratosis: a case report. Cases J. 2008; 1:263. DOI
  17. Ueo T, Kashima K, Daa T. Porocarcinoma arising in Pigmented Hidroacanthoma Simplex. Am J Dermatopathol. 2005; 27:500-3. DOI
  18. Lee JY, Lin MH. Pigmented malignant Hidroacanthoma simplex mimicking irritated seborrheic keratosis. J Cutan Pathol. 2006; 33:705-8. DOI
  19. Zina AM, Bundino S, Pippione MG. Pigmented hidroacanthoma simplex with porocarcinoma. Light and electron microscopic study of a case. J Cutan Pathol. 1982; 9:104-12.
  20. Hilliard NJ, Huang C, Andea A.. Pigmented extramammary Paget’s disease of the axilla mimicking melanoma: case report and review of the literature. J Cutan Pathol. 2009; 36:995-1000. DOI
  21. Culberson JD, Horn RC. Paget’s disease of the nipple; review of twenty-five cases with special reference to melanin pigmentation of Paget cells. AMA Arch Surg. 1956; 72:224-31.
  22. Ho TC, St Jacques M, Schopflocher P.. Pigmented Paget’s disease of the male breast. J Am Acad Dermatol. 1990; 23(2 Pt 2):338-41. DOI
  23. Chiba H, Kazama T, Takenouchi T. Two cases of vulval pigmented extramammary Paget’s disease: histochemical and immunohistochemical studies. Br J Dermatol. 2000; 142:1190-4. DOI
  24. Gumurdula D, Sung CJ, Lawrence WD. Pathologic quiz case: a 63-year-old woman with a pigmented perineal lesion. Extramammary Paget disease. Arch Pathol Lab Med. 2004; 128:e23-4. DOI
  25. Perrotto J, Abbott JJ, Ceilley RI. The role of immunohistochemistry in discriminating primary from secondary extramammary Paget disease. Am J Dermatopathol. 2010; 32:137-43. DOI
  26. Memezawa A, Okuyama R, Tagami H. p63 constitutes a useful histochemical marker for differentiation of pagetoid Bowen’s disease from extramammary Paget’s disease. Acta Derm Venereol. 2008; 88:619-20. DOI
  27. Williamson JD, Colome MI, Sahin A. Pagetoid bowen disease: a report of 2 cases that express cytokeratin 7. Arch Pathol Lab Med. 2000; 124:427-30. DOI
  28. Mai KT, Alhalouly T, Landry D. Pagetoid variant of actinic keratosis with or without squamous cell carcinoma of sun-exposed skin: a lesion simulating extramammary Paget’s disease. Histopathology. 2002; 41:331-6. DOI
  29. Armes JE, Lourie R, Bowlay G. Pagetoid squamous cell carcinoma in situ of the vulva: comparison with extramammary paget disease and nonpagetoid squamous cell neoplasia.. Int J Gynecol Pathol. 2008; 27:118-24. DOI
  30. Chen S, Takahara M, Kido M. Increased expression of an epidermal stem cell marker, cytokeratin 19, in cutaneous squamous cell carcinoma. Br J Dermatol. 2008; 159:952-5. DOI
  31. Conscience I, Jovenin N, Coissard C. P16 is overexpressed in cutaneous carcinomas located on sun-exposed areas. Eur J Dermatol. 2006; 16:518-22.
  32. Imokawa G. Autocrine and paracrine regulation of melanocytes in human skin and in pigmentary disorders. Pigment Cell Res. 2004; 17:96-110. DOI
  33. Imokawa G, Yada Y, Kimura M.. Signalling mechanisms of endothelin-induced mitogenesis and melanogenesis in human melanocytes. Biochem J. 1996; 314(Pt 1):305-12. DOI
  34. Grichnik JM, Burch JA, Burchette J. The SCF/KIT pathway plays a critical role in the control of normal human melanocyte homeostasis. J Invest Dermatol. 1998; 111:233-8. DOI
  35. Elwan NM, El-Ashmawy AA, Gheida SF. Immunohistochemical expression of c-kit receptor (CD117) in two pigmentary disorders. J Clin Exp Dermatol Res. 2013; 4:190. DOI
  36. Maeda K. Large melanosome complex is increased in keratinocytes of solar lentigo. Cosmetics. 2017; 4:49.
  37. Pulitzer M, Desman G, Busam KJ. CK7 expression in primary cutaneous squamous cell carcinoma. J Cutan Pathol. 2010; 37:966-72. DOI
