Abstract

Alveolar adenoma is a rare tumour of the lung. It is typically found in asymptomatic adults as a peripheral or subplerual nodule on imaging examination. Microscopically, the tumour is composed of admixture of epithelial and mesenchymal component in variable sized cystic or alveolar structures. The tumour shows a benign nature. There have been no reported recurrences or metastases. Malignant transformation of alveolar adenoma and coexisting with lung carcinoma have been rarely described. In this article, we report a case of an alveolar adenoma and coexisting atypical adenomatous hyperplasia. This case, contributing to the limited numbers of cases described to date, illustrates the importance of awareness on the possibility of alveolar adenoma being associated with lung carcinoma and its precursor lesions especially when diagnosed by small biopsy specimens.

Introduction

Alveolar adenoma (AA) is a rare pulmonary tumour with proliferation of alveolar epithelium and septal mesenchyme. Yousem and Hochholzer described the first six cases of AA in 1986 ¹. To date, approximately 57 cases have been reported in the literature. AA represents one type of adenoma of lung in the 2021 World Health Organization classification ². There are only few articles about coexistence of AA with other neoplasms ^3-6. Here, we report a rare case of an AA coexisting with atypical adenomatous hyperplasia (AAH). We also review the clinical, radiologic, pathologic and molecular features of AAs.

Case report

A 52-year-old woman, a non-smoker, was incidentally found to have a solitary pulmonary nodule during a regular medical examination. The computed tomography (CT) of the chest revealed a 1.2 cm subpleural nodule in the right upper lobe. The positron emission tomography (PET) scan showed no definite uptake in the nodule. She underwent a wedge resection of the right upper lobe lesion. Frozen section analysis indicated a benign lesion.

The pathological examination of the wedged lung tissue showed a well-demarcated grey white nodule grossly. Microscopic examination disclosed a well-fined tumour containing multiple cystic spaces filled with eosinophilic granular material and lined by flattened to cuboid epithelial cells without significant atypia (Fig. 1A). The associated stroma between the cystic spaces consisted of bland spindle cells, inflammatory cells and myxoid matrix (Fig. 1B).

Immunohistochemically, the lining epithelial cells were positive for pan-cytokeratin (CK), CK7 and thyroid transcription factor 1 (TTF-1) (Fig. 1C). The interstitial cells were focally positive for cluster of differentiation 34 (CD34) (Fig. 1D), while negative for TTF-1 and CK. Both the histopathological and immunohistochemical studies confirmed the lesion to be an AA.

Incidentally, an AAH, 1 mm in size, was identified in the surrounding lung parenchyma. Cytological atypia was found (Figs. 1E, F). There was no parenchymal inflammation or fibrosis in the background. No recurrence or metastasis was observed after 3-year follow up.

Discussion

AAs occur more commonly in women than in men (M:F ratio about 1:2) (Tab. I). The tumour usually presents in the five to sixth decade of life. Most often, patients are asymptomatic. Other symptoms, such as cough, chest pain, dyspnoea and haemoptysis, have been reported. Chest plain film and computed tomography typically show a peripherally or subpleurally located, well circumscribed nodular lesion with occasional central cavitation. There is usually no or minimal, thin-rim contrast enhancement ^4,7. More central location of the lesions has been described ^8-9. The most common location was the left lower lung field. The reported size ranges from 2 mm to 98 mm (average 24 mm). Most of the cases are solitary; however, two cases of multiple occurrences have been reported ^7,10. Few reported cases with follow-up imaging studies have shown slight size enlargement ^11-16. Positron emission tomography (PET) scan often shows no or faint uptake ^8,17.

AAs are grossly well-circumscribed, grey-white or yellow-brownish nodules with a soft, spongy or glistening cut surface. Occasionally they may be cystic or haemorrhagic. Prominent cystic change had been reported ^18-20. Microscopic examination typically shows a well-defined lesion that contains admixture of epithelial and mesenchymal component in variable sized cystic or alveolar structure. Proteinaceous, eosinophilic granular material can be observed in the cysts, some of which may also contain macrophages, fresh blood with cholesterol clefts or hemosiderin-laden macrophages. The larger cysts tend to be concentrated towards the centre of the lesion. Small lymphoid aggregates could be seen at the periphery of the lesion ²¹. Microcystic formation and follicular growth pattern, morphologically mimicking thyroid tissue, has been described ¹⁹.

The cystic spaces are separated by varying thickness of stroma containing mostly bland spindle cells, loose or myxoid matrix, capillaries and scattered inflammatory cells including lymphocytes, plasma cells, and eosinophils. Round-shaped cells as well as spindle-shaped interstitial cells over the septal mesenchyme has been mentioned in one report ²². Foci of interstitial haemorrhage and hemosiderin deposition can be observed ²³. One reported case showed presence of mature adipocytes within the tumour ²⁴. High power examination of the cystic lining shows single layer of flat, cuboidal or hobnail epithelial cells. Nuclear atypia, mitotic activity, and necrosis are absent.

Immunohistochemical analysis of AAs typically shows positive immunoreactivity for CK, CK7, carcinoembryonic antigen (CEA), epithelial membrane antigen (EMA), TTF-1 and surfactant apoprotein in the epithelial component with expression of CK20 in one reported case ^25-26. There is variable immunoreactivity for CD34, smooth muscle actin and S100 in the mesenchymal component ^23-24. The eosinophilic granular material within the cysts is PAS-positive. The proliferation index (Ki-67) is less than 1%. Absence of p53 immunohistochemical expression is found ^{3,5,15-16,22,27}. Based on the immunohistochemical profiles and some ultrastructural studies, the epithelial component of AA is considered to be type II pneumocytes. Additionally, the interstitial cellular component is thought to made up of fibroblasts or fibroblast-like cells ^1,11,25,28.

The exact histogenesis of AA is uncertain. It is unclear if both the epithelial and mesenchymal components are neoplastic. It has been postulated that the cell origin of AA is probably primitive mesenchymal cells with the capacity to differentiate towards type II pneumocytes. Some authors thought of the CD34 immunoreactivity in the interstitial cells as a manifestation of the primitive mesenchymal nature being able to differentiate into specific lineages, such as adipocytes ^23-24. By contrast, the hypothesis that the mesenchymal proliferation is secondary to the epithelial proliferation and stimulated by the epithelial growth has also been proposed ^3,11,29. Limited studies have described the molecular alterations of AA. Cavazza et al. used microsatellite instability analysis to show that the stromal and epithelial components are genetically unrelated, suggesting the dual nature of the lesions ²⁴. Flow cytometric studies of the AAs in some reports showed a diploid DNA pattern ^27-29. Roque et al. reported a non-balanced translocation demonstrated by fluorescence in situ hybridisation analysis ³⁰. The importance of the chromosomal abnormality on the pathogenesis of AA is still unknown. Lack of EGFR mutation and anaplastic lymphoma kinase (ALK) protein expression was shown in one report ¹⁶.

The differential diagnosis of AA comprises both benign and malignant lesions, including sclerosing pneumocytoma (SP), lymphangioma, AAH, adenocarcinoma in situ (AIS) and lepidic predominant adenocarcinoma. Proliferation of both epithelial and stromal component of SP can resemble AA. The absence of diverse growth patterns as well as negative TTF-1 and EMA staining in the mesenchymal component in AA can help one distinguish between these two considerations. Lymphangioma might be confused with AA because both tumours contain cystic structure and proteinaceous material. The flat lining cells of AA may resemble endothelial cells ²⁷. However, unlike AA, lymphangioma does not contain the mesenchymal component. The absence of CK immunoreactivity in the lining cells of lymphangioma also helps to differentiate. Other diagnostic considerations include AAH, AIS and lepidic predominant adenocarcinoma. Areas of small cystic or glandular spaces with regular lining cells in AA might simulate these three entities ¹⁴. Lack of cytologic atypia and infiltrative growth in AA can be helpful features in the differential diagnosis.

The reported cases of AA have had an indolent clinical course. Regardless of the type of surgical intervention, no rrecurrences or metastases have been reported with up to 15 years of follow-up. However, one patient presented with malignant transformation of an AA to an adenocarcinoma in one report ¹⁶. Borderline and transitional areas between the AA and adenocarcinoma has been shown in the case. There are two reported cases of AA with a concurrent lung carcinoma or AIS ^3,6. To the best of our knowledge, our case is the first description of coexisting AA and AAH. AAH is a putative precursor of AIS or lung adenocarcinoma ². The above-mentioned cases including ours, albeit in limited numbers, remind us of the possibility of AA with the potential for malignant transformation or being associated with lung carcinoma and its precursor lesions especially when diagnosed by small biopsy specimens.

Conclusion

In summary, AA is a rare pulmonary tumour often found in asymptomatic adults in their five to sixth decade of life. No recurrences or metastases have been reported to date. It should be considered in the differential diagnosis of a solitary pulmonary nodule. Our case demonstrates the rare occurrence of coexisting AA and AAH. Further molecular analyses might assist in clarifying its pathogenesis and nature.

Figures and tables

Figure 1.(A) In low-power view, the tumour was well defined, containing multiple variable-sized cystic spaces filled with eosinophilic granular material. (haematoxylin-eosin, original magnifications 40X) (B) The epithelial cells lining the cystic spaces were bland, flat to cuboidal. The stroma between the cysts consisted of inflammatory cells, bland spindle shaped cells and loose, myxoid matrix. (haematoxylin-eosin, original magnifications 200X) (C) TTF-1 immunoreactivity was observed in the epithelial cells and negative in the interstitial cells. (original magnifications 200X) (D) The interstitial cells were partially immunoreactive for CD34. (original magnifications 200X) (E) An atypical adenomatous hyperplasia was incidentally identified in the surrounding lung parenchyma. (haematoxylin-eosin, original magnifications 100X) (F) In high-power view, the atypical adenomatous hyperplasia revealed cytological atypia of the proliferative pneumocytes. (haematoxylin-eosin, original magnifications 400X)

References

1. Yousem SA, Hochholzer L. Alveolar adenoma. Hum Pathol. 1986; 17:1066-1071. DOI
2. Beasley MB, Sauter JL. WHO Classification of Tumours Editorial Board. Thoracic tumours. International Agency for Research on Cancer: Lyon (France); 2021.
3. Bhavsar T, Uppal G, Travaline JM. An unusual case of a microscopic alveolar adenoma coexisting with lung carcinoma: a case report and review of the literature. J Med Case Rep. 2011; 5:187. DOI
4. Tang X, Wu Z, Shen Y. Coexistence of lung alveolar adenoma with cerebral arteriovenous malformations: a case report and literature review. Oncol Lett. 2015; 10:250-254. DOI
5. Gan M, Weng S, Zheng H. Coexistence of lung alveolar adenoma with bronchogenic cyst: a case report and literature review. Int J Clin Exp Pathol. 2017; 10:747-749.
6. Yamamoto Y, Toyazaki T, Kosaka S. A surgical case of alveolar adenoma with Tis adenocarcinoma in the same lobe of the lung in a patient with breast cancer. Jpn J Lung Cancer. 2015; 55:228-232. DOI
7. Fujimoto K, Müller NL, Sadohara J. Alveolar adenoma of the lung: computed tomography and magnetic resonance imaging findings. J Thorac Imaging. 2002; 17:163-166. DOI
8. Nosotti M, Mendogni P, Rosso L. Alveolar adenoma of the lung: unusual diagnosis of a lesion positive on PET scan. A case report. J Cardiothorac Surg. 2012; 7:1. DOI
9. Hartman MS, Epstein DM, Geyer SJ. Alveolar adenoma. Ann Thorac Surg. 2004; 78:1842-1843. DOI
10. Lee DS, Hwang MS, Lim JM. A case of alveolar adenoma involving multiple lung nodules. Korean J Med. 2014; 86:623-626.
11. Semeraro D, Gibbs AR. Pulmonary adenoma: a variant of sclerosing haemangioma of lung?. J Clin Pathol. 1989; 42:1222-1223. DOI
12. Cakan A, Samancilar O, Nart D. Alveolar adenoma: an unusual lung tumour. Interact Cardiovasc Thorac Surg. 2003; 2:345-347. DOI
13. Golubovic M, Vuckovic L, Klem I. Alveolar adenoma of lung: a case report. Arch Oncol. 2004; 12:69.
14. Wang X, Li WQ, Yan HZ. Alveolar adenoma combined with multifocal cysts: case report and literature review. J Int Med Res. 2013; 41:895-906. DOI
15. Kondo N, Torii I, Hashimoto M. Alveolar adenoma of the lung: a case report. Ann Thorac Cardiovasc Surg. 2011; 17:71-73. DOI
16. Okada S, Ohbayashi C, Nishimura M. Malignant transformation of alveolar adenoma to papillary adenocarcinoma: a case report. J Thorac Dis. 2016; 8:E358-E361. DOI
17. Roshkovan L, Thompson JC, Katz SI. Alveolar adenoma of the lung: multidisciplinary case discussion and review of the literature. J Thorac Dis. 2020; 12:6847-6853. DOI
18. Petrella F, Rizzo S, Pelosi G. Giant alveolar adenoma causing severe dyspnoea. J Thorac Oncol. 2010; 5:1088-1090. DOI
19. Hsieh MS, Tseng YH, Hua SF. Cystic alveolar adenoma: an unusual clinical presentation of a rare lung neoplasm. Pathology. 2015; 47:78-80. DOI
20. Volk L, Minerowicz C, Saadat S. Multicystic alveolar adenoma in a symptomatic adult with extensive bullae and mediastinal shift. Surgical Case Reports. 2020; 3:2-3. DOI
21. Hamid Kazerouni A, Chetty R. Alveolar adenoma of the lung. Diagnostic Histopathology. 2013; 19:311-313. DOI
22. Zhang X, Bai Y, Wang X. Alveolar adenoma with the round-shaped mesenchymal cells: a rare case and review of literature. Int J Clin Exp Med. 2017; 10:3936-3939.
23. De Rosa N, Maiorino A, De Rosa I. CD34 Expression in the stromal cells of alveolar adenoma. Case Rep Med. 2012; 2012:913517. DOI
24. Cavazza A, Paci M, De Marco L. Alveolar adenoma of the lung: a clinicopathologic, immunohistochemical, and molecular study of an unusual case. Int J Surg Pathol. 2004; 12:155-159. DOI
25. Halldorsson A, Dissanaike S, Kaye KS. Alveolar adenoma of the lung: a clinicopathological description of a case of this very unusual tumour. J Clin Pathol. 2005; 58:1211-1214. DOI
26. Köppl H, Freudenberg N, Berwanger I. Alveolar adenoma of the lung. Immunohistochemical characterization of type II pneumocytes. Pathologe. 1996; 17:150-153. DOI
27. Sak SD, Koseoglu RD, Demirag F. Alveolar adenoma of the lung. Immunohistochemical and flow cytometric characteristics of two new cases and a review of the literature. APMIS. 2007; 115:1443-1449. DOI
28. Burke LM, Rush WI, Khoor A. Alveolar adenoma: a histochemical, immunohistochemical, and ultrastructural analysis of 17 cases. Hum Pathol. 1999; 30:158-167. DOI
29. Oliveira P, Moura Nunes JF, Clode AL. Alveolar adenoma of the lung: further characterization of this uncommon tumour. Virchows Arch. 1996; 429:101-108. DOI
30. Roque L, Oliveira P, Martins C. A nonbalanced translocation (10;16) demonstrated by FISH analysis in a case of alveolar adenoma of the lung. Cancer Genet Cytogenet. 1996; 89:34-37. DOI
31. Al-Hilli F. Lymphangioma (or alveolar adenoma?) of the lung. Histopathology. 1987; 11:979-980. DOI
32. Böhm J, Fellbaum C, Bautz W. Pulmonary nodule caused by an alveolar adenoma of the lung. Virchows Arch. 1997; 430:181-184. DOI
33. Yilmaz A, Bayramgürler B, Aksoy F. Alveolar adenoma: a rare benign tumour of the lung. Tuberkuloz ve Toraks Dergisi. 2002; 50:78-80.
34. Papla B, Malinowski E. Alveolar adenoma of the lung - a report of two cases. Pol J Pathol. 2003; 54:147-152.
35. Saito EH, de Aaraujo LR, Carneiro LH. Alveolar adenoma. J Bras Pneumol. 2006; 32:267-269. DOI
36. Nakamura H, Adachi Y, Arai T. A small alveolar adenoma resected by thoracoscopic surgery. Ann Thorac Surg. 2009; 87:956-957. DOI
37. González ET, Sánchez-Yuste R, Jiménez-Heffernan JA. Cytologic features of pulmonary alveolar adenoma. Acta Cytol. 2008; 52:739-740. DOI
38. Panagiotou I, Kostikas K, Sampaziotis D. Alveolar adenoma: an extremely rare innocent coin lesion. Interact Cardiovasc Thorac Surg. 2012; 14:335-337. DOI
39. Wang L, Wang X, Rustam A. Alveolar adenoma resected by thoracoscopic surgery. Ann Thorac Cardiovasc Surg. 2013; 19:489-491. DOI
40. Kavas M, Öztürk A, Derdiyok O. Rare lung tumours: alveolar adenoma-four case reports. Turk Thorac J. 2019; 20:203-205. DOI
